DIATONE MAMBA TOKA 1206 2450kv, 3600kv Or 4500kv Series Racing Motor

DIATONE MAMBA TOKA 1206 2450kv, 3600kv Or 4500kv Series Racing Motor - Image 2

DIATONE MAMBA TOKA 1206 2450kv, 3600kv Or 4500kv Series Racing Motor - Image 3

DIATONE MAMBA TOKA 1206 2450kv, 3600kv Or 4500kv Series Racing Motor

Original price was: $12.99.Current price is: $9.09.

SKU: YNVKZ 6830058700988 Categories: Diatone, FPV & Quad Tag: Discountable

Buy with confidence, backed by quality.
Quality products, fair prices.
Buy with Peace of Mind
Effortless Shopping, Quality Products

DIATONE MAMBA TOKA 1206 Series Racing motor

MAMBA TOKA 1206 2450KV Racing motor

Overall Dimension:Φ17×13.4mm
prop mounting shaft diameter:1.5mm
Installation hole position: 9×9mm，M2
Prop: 2inch~3inch
Bearing：5*2*2.5
Shaft Diameter:2mm
Lead Wire Size：24AWG×150mm
Configuration:9N12P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：12mm
Stator Height:6mm
Rated Voltage:4~6S (16.8V~25.2V)
Peak Current: 5.8A
ldle Current：6V/0.4A
Maximum Power: 160W
Internal Resistance：456Ω

MAMBA TOKA 1206 3600KV Racing motor

Overall Dimension:Φ17×13.4mm
prop mounting shaft diameter:1.5mm
Installation hole position:9×9mm，M2
Prop: 2inch~3inch
Bearing：5*2*2.5
Shaft Diameter:2mm
Lead Wire Size：24AWG×150mm
Configuration:9N12P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：12mm
Stator Height:6mm
Rated Voltage:3~4S (12.6V~16.8V)
Peak Current: 10A
ldle Current：6V/0.4A
Maximum Power: 160W
Internal Resistance：236Ω

MAMBA TOKA 1206 4500KV Racing motor

Overall Dimension:Φ17×13.4mm
prop mounting shaft diameter:1.5mm
Installation hole position:9×9mm，M2
Prop: 2inch~3inch
Bearing： 5*2*2.5
Shaft Diameter:2mm
Lead Wire Size：24AWG×150mm
Configuration:9N12P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：12mm
Stator Height:6mm
Rated Voltage:3~4S (12.6V~16.8V)
Peak Current: 10.7A
ldle Current：6V/0.6A
Maximum Power: 128W
Internal Resistance：168Ω
