DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green

DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green - Image 2

DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green - Image 3

DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green - Image 4

DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green - Image 5

DIATONE MAMBA TOKA 1408 2900KV Or 4100KV Racing Motor Green

Original price was: $14.99.Current price is: $10.49.

SKU: YNVKZ 6829355466940 Categories: Diatone, FPV & Quad Tag: Discountable

Buy with confidence, backed by quality.
Quality products, fair prices.
Buy with Peace of Mind
Effortless Shopping, Quality Products

DIATONE MAMBA TOKA 1408 2900KV or 4100KV Racing Motor Green

Specification:

Mamba Toka 1408 2900KV Racing Motor Green

Overall Dimension:Φ20.6×18.5mm
prop mounting shaft diameter:1.5mm
Installation hole position:12×12mm，M2
Prop: 3inch~4inch

Bearing：5*2*2.5
Shaft Diameter:2.0mm
Lead Wire Size：24AWG×150mm
slots/poles:9N12P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：14mm
Stator Height:8mm
Rated Voltage:4~6S (16.8V~25.2V)
Peak Current: 15.75A
ldle Current：10V/0.4~1.0A
Maximum Power: 376.3W
Internal Resistance：135Ω

1408 2900KV motor table

Mamba Toka 1408 4100KV Racing Motor Green

Overall Dimension:Φ20.6×18.5mm
prop mounting shaft diameter:1.5mm
Installation hole position:12×12mm，M2
Prop: 3inch~4inch
Bearing：5*2*2.5
Shaft Diameter:2.0mm
Lead Wire Size：24AWG×150mm
slots/poles:9N12P
Magnet Wire: 240℃ Enameled Wire
Stator Diamter：14mm
Stator Height:8mm
Pated Voltage:3~4S (12.6V~16.8V)
Peak Current: 19.5A
ldle Current：10V/0.8~1.5A
Maximum Power: 376.3W
Internal Resistance：85Ω
